Tippers Body Raised Warning & Anti Lock System
Transport Support is pleased to announce the launch of a new body raised warning system that has been designed to prevent tipper vehicles (or vehicle that can raise parts of the body) from driving with the tipper body raised and colliding with bridges and other overhead obstacles.
Engineered in Bangalore. Tested across 14 mining states. Backed by a 4-hour SLA service network.
Engineered for the toughest mining environments.
tipper body is raised with an audible/visual warning at all times. When Tipper Body raised, our Device inter lock the brake systems. It’s not allowed to move forward and backward. Our device controls the brake system, until tipper body not closed properly. Prevents accidental activation of the tipping system. The Tipper Body Raised Warning system consists of a small ECU that is mounted under the dash in the driver’s cab. Our product has built-in VOICE CONTROLLER and LEDs Indicators that allows the driver to activate the system and give them feedback on body raised position with Audio /Visual alerts. The driver raises the tipper body as normal. As soon as the tipper body is raised off the chassis.
Datasheet
| Audio Alert | Human Voice Warning - TRUCK KA DALLA UPPAR HAI, KRUPIYA DALLA NICHE KARRE |
| LED Lights | 12 Nos LED Indicators |
| Controller Unit | Input Voltage 10VDC - 32VDC |
| Sensor | Chemically Sealed for Dust and Moisture Protection |
| Solenoid Valve | Working Voltage 12VDC or 24VDC |
| Color | Black |
